With the success of both the Process 134 and the Remote 160, it only made sense to blend the two and create the ultimate trail e-MTB. The Remote 130 strikes a perfect harmony between an all-mountain trail bike and pedal-assist electric bike. A sturdy aluminum frame holds Shimano's E7000 motor and 504 Wh battery. Suspension is provided by a 140mm Fox Rhythm 34 Float fork and Performance Float rear shock. Shimano's new 12-speed Deore drivetrain and 4-piston brakes provide the stop and go. 29" WTB KOM Trail i35 TCS 2.0 wheels are wrapped in Maxxis Minion EXO+ TR 3C rubber. The bike is finished off with a stellar Prism paint job that is sure to be a showstopper on trails everywhere.
Kona 6061 Aluminum
Kona 7005 and 6061 Aluminum alloys are used extensively throughout our fleet of mountain and asphalt bicycles. A tough, durable, light alloy, both Kona 7005 and 6061 deliver fantastic, reliable performance that lasts for thousands of rides. Much of our 7005/6061 tubing is butted and/or formed, meaning the tubing's wall thickness can be increased or decreased, as well as shaped, so we can fine-tune a particular frame's strength and ride characteristics depending on its intended application.
Bearing cups are actually pressed into the frame and are easily removable. An internal headset also reduces stack height, so the height of the stem and bars are more adjustable, giving the rider the best fit possible.
Tapered Head Tube
More girth at the bottom of the head tube better distributes shock force, prolonging the bearing life of the headset itself and eliminating brake shudder, while providing confident steering performance. The inherent strength of its triangular design also means a stronger steering position and improved balance, giving the rider more control in rough terrain. A zero-stack, tapered head tube also puts strength where the load is going—into the lower headset cup—maximizing bearing durability where it's needed.
Tubeless Compatible Rims
Tubeless rims allow for tires with more puncture resistance; the ability to run lower tire pressure, which provides better tire grip on the trail; lower rolling resistance; and weight savings over traditional tube and tire systems.
12x142mm, 12x148, and 12x157 rear axle standards provide two major advantages to the Kona rider: the 12mm diameter of the rear axle provides the rear hub and frame with a stiff interface, while the 142/148/157mm outer diameter of the hub allows the wheel to be quickly and properly positioned in the frame before the rear axle is inserted.
Beamer Independent Suspension
Built to be off-the-top progressive, Beamer Independent Suspension helps the bike to stay higher in the travel and recover from hits more quickly. The Operators are instilled with what our product managers like to call "pure shock movement," whereby the shock is protected from side load. Designed to be highly tuneable and extremely durable, the Beamer IS is our version of greased lightning.
|Display||Shimano SC-E7000 Display|
|Max Assisted Speed||20mph|
|Charger||Shimano STEPS 2A|
|Frame||Kona 6061 Aluminum Butted 130mm Travel|
|Fork||Fox Rhythm 34 Float 140mm Tapered 110 Spacing|
|Rear Shock||Fox Performance Float Trunnion|
Front: 110 x 15mm thru-axle
Rear: 148 x 12mm thru-axle
|Rims/Wheels||WTB KOM Trail i35 TCS 2.0|
|Spokes||Stainless Black 14g|
Front: Maxxis Minion DHF EXO+ TR 3C 29x2.5" WT
Rear: Maxxis Minion DHR II EXO+ TR 3C 29x2.4" WT
|Rear Derailleur||Shimano Deore|
|Cassette/Rear Cogs||Shimano Deore 10-51t 12spd|
|Handlebars||Kona XC/BC 35|
|Tape/Grips||Kona Key Grip|
|Stem||Kona XC/BC 35|
|Brake Levers||Shimano Deore|
|Seat Post||Trans-X Dropper Internal 31.6mm|
* Subject to change without notice.
|Gloss Prism Rust-Purple / Large||841073140114||B21RE13005||210000043543|
